JACK-AIVA Machinery CO,.LTD
DUCTWORK MACHINERY MANUFACTURER
 |
| Place of Origin: | China |
| Brand Name: | Jack-Aiva |
| Certification: | CE SGS |
| Minimum Order Quantity: | Negotiable |
|---|---|
| Price: | Negotiable |
| Delivery Time: | 60 working days |
| Payment Terms: | T/T L/C |
| Product Name: | Flexible Duct Collar Stick Machine | Tube Diameter:: | ￠80-￠600mm |
|---|---|---|---|
| Length Of Duct:: | 100mm-8,000mm | Aluminum Foil Thickness:: | 0.25mm (as Reference) PET+ Aluminum Foil |
| Production Efficiency: | Around 2pcs/min | Main Power:: | 0.5KW |
| Weight: | 250KG | Sizes: | 1200mm * 820mm * 950mm |
| High Light: | 100mm Collar Stick Machine,8000mm Duct Making Machine,600mm Duct Making Machine |
||
Flexible Duct Collar Stick Machine
Stick Machine for the collar of Flexible Aluminum Foil Duct with Steel Wire
This is the sealing machine for production the Flexible duct collars. To stick the tap on both flex ducts, one side is for inner joint and another side is for the outer joint. So the both side diameter are not same, to make the flexible ducts connection more easy and simple.
With the new design, there have two sets of tap decoilers and rolling system. to make the production efficiency is more high than old one. .
Main Parameters - Tap stick machine for flexible ducts collars
| ITEM | CONTENT |
| Tube Diameter: | ￠80-￠600mm (according to client requirements) |
| Length of duct: | 100mm-8,000mm |
| Aluminum Foil Thickness: | 0.25mm (as reference) PET+ Aluminum foil |
| Aluminum Foil Width: | according to duct diameter or client requirements |
| Production efficiency | Around 2pcs/min |
| Main Power: | 0.5KW |
| Weight | 250KG |
| Sizes | 1200mm * 820mm * 950mm |
Flexible Aluminum Air duct Applications
